Description
AJMU137PMQW Cordless Mag Drill 18V AMPShare SELECT (Tool Only) – 71700562090
DETAILS
- Extremely durable cordless mag drill with a FEIN PowerDrive designed for up to 60,000 holes during a 300 h usage period.
- Lightweight tool that delivers up to 25% more battery life than our competitors. Using CORE 18V 12 Ah battery, up to 48 holes per charge (11/16″ diameter on 1/2″ mild steel plate).
- The lightest cordless mag drill in the world at only 26.9 lbs. This drill features forward/reverse, electronic speed control, and 10-1/4″ stroke range for maximum flexibility in all applications (drilling, tapping, twist drilling, reaming and countersinking).
- Intuitive operator controls located on the top of the drill motor for maximum visibility.
- A Convenient magnetic holding force indicator supports the safe positioning of the tool.
- Workplace Safety: Tilt sensor safety shutoff will shut down the drill in the event it should move or break free from the workpiece.
- MK2 tool mount for direct use of industrial tools.
- Secure position thanks to extra narrow permanent magnet with pre-magnetization for convenient and simple alignment.
- “Memory function” speed storage.
- COOLPACK 2.0 technology ensures a 135% longer battery service life, enabling longer operation time.
- State-of-the-art cell technology and intelligent battery management deliver 87% more power than conventional batteries.
- CORE 18 V Li-ion battery with Highpower cells, charge indicator and electronic cell protection (ECP). ECP protects batteries against overloading, overheating and deep discharge.
- * optional using accessory.
- ** Maximum performance with AMPShare CORE 18 V 8.0 Ah / 12.0 Ah
TECHNICAL DATA: |
|
| Battery voltage | 18V |
| Cutter holder | 3/4″ straight shank |
| Battery compatibility | Li-ion / CORE 18 V Li-ions** |
| Battery interface | 18 V AMPShare |
| Motor | Brushless |
| Full load speed | 130 – 520 rpm |
| Tool mount | MT 2 |
| Carbide cutter max. dia. | 1-3/8 [35] in[mm] |
| HSS cutter max. dia. | 1-3/8 [35] in[mm] |
| Cutter max. drilling depth | 2 [50] (3 [75] )* in[mm] |
| Twist drill max. dia. | 3/4 [18] in[mm] |
| Tapping | 1/2″ |
| Max. countersinking dia. | 1-1/4 [31] in[mm] |
| Reaming max. dia. | 3/4 [18] in[mm] |
| Cutter change | tool-free |
| Stroke | 5-5/16 [135] in[mm] |
| Total stroke range | 10-1/4 [260] in[mm] |
| Magnetic holding force | 2023 [9,000] lbs[N] |
| Magnetic base dimensions | 7-11/16 [195] x 2-3/4 [70] in[mm] |
| Weight without battery | 26.90 [12.20] lbs[kg] |
VIBRATION AND SOUND EMISSION VALUES: |
|
| Sound pressure level LpA | 81,6 bB |
| Measurement uncertainty of the measured value KpA | 5 dB |
| Sound power level LWA | 94,6 dB |
| Measurement uncertainty of the measured value KWA | 5 dB |
| Peak sound value LpCpeak | 92,2 dB |
| Measurement uncertainty of the measured value KpCpeak | 5 dB |
| Vibration value 1 αhv 3-way | ah,D 0,6 m/s² |
| Measurement uncertainty of the measured value Kα | 1,5 m/s² |
