Description
MODEL VO-225
Vibrator Motor, Oztec, 2.25HP
The heavy-duty solution for efficient concrete consolidation. Built tough with a rugged housing and powered by an oversized 2.25HP motor, these vibrators ensure excellent results every time. With quick-release carbon brushes for easy maintenance and top and rear handles for maneuverability, get the job done with ease and reliability.
FEATURES
- Oztec-compatible quick-connect
- Oversized, double-insulated 2.25HP motor
- Covers all applications and shafts (up to 20-ft)
- Highly resistant IP44 housing
- Quick-release carbon brushes
- Top and rear handles for easy maneuverability
- Shoulder strap included
- Designed and manufactured in Europe
SPECIFICATIONS
| Horsepower | 2.25 HP |
|---|---|
| Amperage (A) | 15 A |
| Voltage (V) | 120V |
| Wattage (W) | 1,800W |
| RPM | 12,000 |
| Weight (LBS) | 12.8 |
| Length | 13.5″ |
| Width | 6″ |
| Height | 8.5″ |
| Warranty | 1 Year |
| Certification | ETL |
SHAFTS |
||
| 7 FOOT SHAFT | PA-VOS07 | |
| 10 FOOT SHAFT | PA-VOS10 | |
| 13 FOOT SHAFT | PA-VOS13 | |
| 16 FOOT SHAFT | PA-VOS16 | |
| 20 FOOT SHAFT | PA-VOS20 | |
HEADS |
||
| 1″ HEAD | PA-VPH100 | |
| 1-1/4″ HEAD | PA-VPH125 | |
| 1-1/2″ HEAD | PA-VPH150 | |
| 1-3/4″ HEAD | PA-VPH175 | |
| 2-1/4″ HEAD | PA-VPH225 | |
SHAFTS / MOTORS ARE INTERCHANGE WITH OZTEC-BUILT UNITS.
HEADS CANNOT INTERCHANGE
